| Product |
IdeaCentre AIO 24IRH9 |
| Model |
F0HN00VNLK |
| PERFORMANCE |
|
| Processor |
Intel Core™ i7-13620H, 10C (6P + 4E) / 16T, P-core up to 4.9GHz, E-core up to 3.6GHz, 24MB Intel® Smart Cache |
| Graphics |
Integrated Intel® UHD Graphics |
| Chipset |
Intel® SoC Platform |
| Memory |
1x 8GB SODIMM DDR5-5200 |
| Memory Slots |
Two DDR5 SODIMM slots, dual-channel capable |
| Max Memory |
Up to 24GB DDR5-5200 |
| Storage |
512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® |
| Optane Memory |
None |
| Max Storage Support |
One drive, up to 1TB M.2 SSD |
| Card Reader |
No Card Reader |
| Optical |
None |
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC233-CG codec |
| Speakers |
3Wx2, HARMAN |
| Camera |
5.0MP |
| Microphone |
Dual Microphone |
| Power Supply |
90W 89% Adapter |
| DESIGN |
|
| Display |
23.8″ FHD (1920×1080) IPS Anti-glare 250nits, 100Hz, 99% sRGB, hardware low blue light, 3-side borderless, non-touch |
| Touchscreen |
None |
| Keyboard |
Wireless EOS Keyboard, Luna Grey, English |
| Mouse |
Wireless EOS Mouse, Luna Grey |
| Expansion Slots |
Two M.2 slots (one for WLAN, one for SSD) |
| Case Color |
Luna Grey |
| Stand |
AIO Stand |
| Wireless Charger |
No Wireless Charger |
| Pen |
Pen Not Supported |
| Form Factor |
AIO (23.8 inches) |
| Dimensions (WxDxH) |
540 x 192 x 431 mm (21.25 x 7.56 x 16.97 inches) |
| Weight |
Around 6.0 kg (13.23 lbs) |
| CONNECTIVITY |
|
| WLAN + Bluetooth |
Wi-Fi® 6, 802.11ax 2×2 + BT5.2 |
| WWAN |
WWAN Not Supported |
| Ethernet |
Integrated 100/1000M |
| Rear Ports |
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), 2x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI®-in 1.4, 1x HDMI®-out 2.1 TMDS, 1x Ethernet (RJ-45), 1x power connector |
| Left Ports |
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only, 1x headphone / microphone combo jack (3.5mm) |
| SECURITY & PRIVACY |
|
| Security Chip |
Firmware TPM 2.0 integrated in SoC |
| SERVICE |
|
| Base Warranty |
2 years Standard Warranty |
| CERTIFICATIONS |
|
| Green Certifications |
ErP Lot 3/7, GREENGUARD®, RoHS / WEEE / REACH |
| Other Certifications |
TÜV Rheinland® Flicker Free, TÜV Rheinland® Low Blue Light, TÜV Rheinland® Ultra Low Noise |
