| User Capacity |
30,000 (optional 50,000) |
| Face Capacity |
30,000 (optional 50,000) |
| Card Capacity |
30,000 (optional 50,000) |
| Fingerprint Capacity |
10,000 (optional 30,000) (G4 Pro FP) |
| Transaction Capacity |
1,000,000 |
| Hardware |
64bit 8-Core Customized Computer Vision CPU, 2GB LPDDR3 / 16GB eMMC, 7-inch Touch Screen (720*1280 Pixels), 2MP Binocular Camera |
| Wired |
TCP/IP, USB Host, RS485, Wiegand Input/Output LTE FDD B1/B2/B3/B4/B5/B7/B8/B20/B28 |
| Wireless |
Wi-Fi, Bluetooth, 4G |
| WLAN |
2.4G, 802.11 b/g/n WCDMA B1/B2/B4/B5/B8 |
| Bluetooth |
BT2.1+EDR/3.0/4.1 LE/4.2 BLE GSM 850/900/1800/1900MHz |
| LTE FDD |
B1/B2/B3/B4/B5/B7/B8/B20/B28 |
| LTE TDD |
B38/B39/B40/B41 |
| WCDMA |
B1/B2/B4/B5/B8 |
| GSM |
850/900/1800/1900MHz |
| Card |
125kHz ID card & 13.56MHz IC card, Multi-tech Card Module (optional) |
| QR Code Scanner |
Dynamic QR codes on the ZKBioSecurity mobile APP. QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in 3rd-party development projects |
| Fingerprint |
Z-ID Fingerprint Sensor (ZKFinger 10.0) |
| Face |
ZKFace 5.6 Algorithm, Recognition Speed ≤ 0.5s, Recognition Distance 0.5m to 3m |
| Access Control |
RS485 (OSDP v2.1.7), Wiegand In/Out, Lock Relay Output, Exit Button, Alarm Output, Auxiliary Input, Door Sensor, External Bell |
| Power Supply |
DC 12V, 3A. IEEE 802.3af/at |
| Operating Temperature |
-20°C to 55°C |
| Operating Humidity |
<90%RH |
| Storage Humidity |
<90% |
| Storage Temperature |
-25°C to 65°C |
| Dimensions (H*L*D) |
264mm*120mm*51mm |
