| Capacity |
1500VA |
| Input |
|
| Voltage Range |
140 ~ 300V ±5% |
| Frequency |
50Hz/60Hz (Auto-sensing) |
| Phase |
Single + GND |
| Output |
|
| Voltage Range |
230VAC +12% -14% |
| Battery Mode |
230VAC +10% -10% |
| Frequency |
50Hz ±1% (Battery mode) |
| Waveform |
Simulated sine wave (Battery mode) |
| Sine wave (AC mode) |
| Transfer Time |
2ms typical |
| Battery |
|
| Type |
12V/10AH – 2pc |
| Backup Time |
Up to 40 mins depending on load |
| Recharge Time |
2 – 4 hours recover to 90% capacity |
| Protection / Monitoring |
|
| Short Circuit Protection |
Yes (Line mode & battery mode) |
| Surge Protection |
Yes |
| Alarm |
Audible & visual |
| UPS Protection |
Load auto sensing and abnormal protection |
| Overload Protection |
Line mode : 110 – 120% 5 mins & shutdown |
| >120% shutdown immediately |
| Battery mode : 100 – 110% alarm & shutdown in 10 secs |
| >120% shutdown immediately |
| Intelligent Battery |
Prevent overcharging of battery |
| Management |
Protect battery and prolong battery life |
| Interface |
|
| RJ45 Ports |
Modem/Fax Protection |
| USB Connector* |
AC fault, battery low, shutdown UPS |
| General |
|
| Software |
Support Windows® 2000/ 2003/ XP/ Vista/ 2008/ 7, Linux, Unix, and Mac |
| Noise Level |
<40dB |
| Temperature |
0°C – 40°C |
| Humidity |
0 – 90% |
| Power Factor |
Up to 0.7 |
| Built-in AVR |
TRUE Full AVR (3 steps) |
| Physical |
|
| Dimension (D x W x H) |
320 x 130 x 182mm |
| Weight |
10.4kg |
| Warranty Information |
|
| Warranty |
1 Year |
